Multi-Digit Pro + Angle Finder

INSIST on GEO FENNEL

GERMAN QUALITY & ACCURACY

All-in-one

Electronic angle measurer, electronic slope measurer and laser spirit level. Easy and accurate. For measuring angles, inclinations, sloped and plane surfaces.

Features

  • Displays angle and inclination simultaneously
  • Different signal tones when approaching 0° / 90° and continuous tone at 0° / 90°
  • Inclination direction indication
  • Zero position re-set at any position
  • Automatic digit inversion for overhead measurements
  • Visible laser beam to extend working range
  • HOLD function to freeze measurement
  • Illuminated display
  • Magnetic base
  • 1/4“ thread for camera tripod
  • 180° lock to extend the unit to 1 m length
  • Arm can be locked in any position

Supplied with

  • Padded bag
  • Batteries

Technical data

Working range inclination 4 x 90°
Resolution 0.1° / 0.1%
Accuracy inclination 0° and 90° = ± 0.1°
1° - 89° = ± 0.2°
Measuring units °, %, mm/m, in/ft
Working range angle 0° – 180°
Resolution 0.1° / 0.1%
Accuracy angle ± 0.1°
Working range laser 20 m
Accuracy laser ± 0.5 mm / 1 m
Wave length / laser class 650 nm / 2
Power supply 3 x AA Alkaline
Operating time w/o laser 48 h
with laser 20 h
Temperature range -10 °C bis +45 °C
Weight (incl. Batteries) 1.3 kg
Size 520 x 63 x 30 mm
Unfolded length 1000 mm
Shipping
This Item Ships from Fremantle, Perth, Western Australia



Please allow 2 - 10 days for your order to arrive. Although Most Stocked Products will generally Ship Overnight.  We source products from all over the world to bring you epic offers and the lowest prices. This means sometimes you have to wait a little longer to get your order but it's always worth it!

Returns are easy, simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!





Here are 5 more great reasons to buy from us:



You get a full 30 days to return your item to us. If your product is faulty or damaged under manufacture warranty, simply send it back to us and we'll cheerfully replace it or fix the problem for you.

Returns are easy, simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!

In the unlikely event that you find your item cheaper at another online store, just let us know and we'll beat the competitor's pricing hands-down.

We insist that you love everything you buy from us. If you're unhappy for any reason whatsoever, just let us know and we'll bend over backwards to make things right again.

Ordering from Laserman Technologies is 100% safe and secure so you can rest easy. Your personal details are never shared, sold or rented to anyone either.
