Z-Laser ZQ1 Series Line Laser (12–24 VDC)

SKU: 750115011
$8,132.00

Model

Checkout Secure
Need more info? Call us +61 8 9335 1718
Model Product # Wavelength Output power Recommended working distance Projection Fan angle Laser class
Z1300-Q1-F-450-elp45 750115011 450nm 1300mW below 3.3ft (1m) Homogeneous line 45° 3B
Z1000-Q1-F-450-slp45 750115019 450nm 1000mW above 3.3ft (1m) Homogeneous line 45° 3B
Z1000-Q1-F-640-elp45 750135017 640nm 1000mW below 3.3ft (1m) Homogeneous line 45° 3B
Z800-Q1-F-640-slp30 750135029 640nm 800mW above 3.3ft (1m) Homogeneous line 30° 3B
Z1000-Q1-F-660-elp45 750135027 660nm 1000mW below 3.3ft (1m) Homogeneous line 45° 3B
Z800-Q1-F-660-slp30 750135028 660nm 800mW above 3.3ft (1m) Homogeneous line 30° 3B
Z1700-Q1-F-808-elp30 750145005 808nm 1700mW below 3.3ft (1m) Homogeneous line 30° 3B

Compact high-performance module

The ZQ1 laser series has been designed for the most demanding measurement applications on the market. Wherever high output power, excellent beam characteristics and industrial-grade design are required, the ZQ1 series is the right choice. Thanks to the tool-free focusing, the user can optimally adjust the working distance of the module to the application requirements. Combined with its intelligent monitoring functions, the laser allows for high power stability even in harsh environments. The integrated active peltier cooling supports this function by keeping the laser diode constantly in the optimal temperature range.

  • Repeatable high product quality due to automated production processes
  • Optical output power up to 2.500 mW (450 nm)
  • Standard wavelengths from 405 – 808 nm
  • Manually focusable
  • Active cooling integrated
  • TTL modulation up to 200 kHz
  • Analog intensity control
  • IP 67
  • Certified according to the railway standard: DIN EN 61373:2011-04
  • PC control via Graphical User Interface (GUI)



Weight 690 g
Dimensions 158.5 × 65.2 × 51.5 mm
Wavelength

405 nm, 450 nm, 520 nm, 640 nm, 660 nm, 808 nm

Output power

1000 mW, 1700 mW

Fan Angle

10°, 20°, 30 degrees, 45 degrees, 5 degrees, 60 degrees, 75 degrees, 90 degrees

Projection

dot, line

Focus

manual focus

Modulation

analog, digital

Supply voltage

12 VDC – 24 VDC

IP protection class

IP 67

Application

Machine Vision, OEM
