Component | Specification | |||||||||||
Model Name | D18-HD | |||||||||||
Model Number | VX113-2 | |||||||||||
Application | Used with the Type-MX reel in pipe diameters from 1-1/2 to 3 inches / 38 to 75mm | |||||||||||
Resolution | 1080p | |||||||||||
Active Pixels | 1920 x 1080 | |||||||||||
Focus Point | 4" (10cm) | |||||||||||
Aperture / FOV | 90º | |||||||||||
Lighting | 69 Lumens Measure at 1 meter in 4-inch cast iron pipe | |||||||||||
Auto Upright | None, fixed position non-leveling camera | |||||||||||
Construction | Stainless steel housing with scratch-resistant Sapphire lens | |||||||||||
Environmental | Water resistance up to 11 BAR pressure | |||||||||||
Temperature Range | Storage: -4ºF to 158ºF (-20ºC to +70ºC), Operating: 14ºF to 122ºF (-10ºC to +50ºC) | |||||||||||
Manufacturing | Designed and manufactured per ISO 9001:2015 | |||||||||||
Dimensions Installed | 0.73” (Dia.) x 0.71” (L) / 18.6mm (Dia.) x 18.1mm (L) without standard skid 1.0” (Dia.) x 0.73” (L) / 25.6mm (Dia.) x 18.6mm (L) Diameter with standard skid installed |
|||||||||||
Weight | 0.029lbs (0.013kg) without standard skid | 0.035lbs (0.016kg) with standard skid | ||||||||||
Options | Optional 2.5 / 57mm Guide skid | Camera exchange program | ||||||||||
What’s in the Box | D18-HD Camera | Standard Skid |
Component | Specification | |||||||||||
Model Name | D26-HD | |||||||||||
Model Number | VX112-3 | |||||||||||
Application | Used with the Type-MX reel in pipe diameters from 2 to 4 inches / 50 to 101mm | |||||||||||
Resolution | 1080p | |||||||||||
Active Pixels | 1920 x 1080 | |||||||||||
Focus Point | 6" (15cm) | |||||||||||
Aperture / FOV | 114º | |||||||||||
Auto Upright | Cantilever self-leveling design | |||||||||||
Construction | Stainless steel housing with scratch-resistant Sapphire lens | |||||||||||
Environmental | Water resistance up to 10 BAR pressure | |||||||||||
Temperature Range | Storage: -4ºF to 158ºF (-20ºC to +70ºC), Operating: 14ºF to 122ºF (-10ºC to +50ºC). | |||||||||||
Manufacturing | Designed and manufactured per ISO 9001:2015 | |||||||||||
Dimensions Installed | 1.02” (Dia.) x 1.41” (L) / 26mm (Dia.) x 35.9mm(L) without standard skid 1.33” (Dia.) x 1.41” (L) / 33.7mm (Dia.) x 35.9mm(L) with standard skid |
|||||||||||
Weight | 0.14lbs (0.065kg) without standard skid | 0.16lbs (0.073kg) with standard skid | ||||||||||
Options | Optional 2.5 and 3" guide skids (57 and 75mm) | Camera exchange program | ||||||||||
What’s in the Box | D26-HD Camera | Standard Skid |
Shipping | This Item Ships from Fremantle, Perth, Western Australia |
