Geo-Fennel New Products 2021 -2022

LINE LASERS

1. GeoSpider GREEN | Contact us for pricing

GeoSpider (red laser) will be stopped and replaced by GeoSpider GREEN.

GeoSpider GREEN will be much cheaper than the former red.

2. FLG 70 GREEN | Contact us for pricing

Multi-Line laser for highest accuracy and measurement requirements.

FL 70 => FLG 70-GREEN

Manual slope: laser plane can be tilted in coarse + fine steps by use of remote control.

Accuracy +/- 1 mm / 10 m
Highly visible green laser lines up to 30 m
Working range 80 m with receiver
Li-Ion battery
Slope setting in 2 steps -Coarse: 1 press = 3 mm step at 15 m distance -Fine: 1 press = 1 mm step at 15 m distance

MULTI-FUNCTIONAL MOUNT FOR LINE LASERS

3. MH 1 | Contact us for pricing

Multi-functional mount for line & dot lasers

Height adjustable platform with slow motion wheel - range 85 mm
Platform with -Forward/back shift 20 mm -Left/right shift 200°
Magnets on back side
Screw hole for wall-attachment
Metal plate for safe stand *1/4" & 5/8" connection
Weight 0,52 kg

4. WS 1 | Contact us for pricing

Wall adapter

Adapter for clamp connection at wall track for dropped ceiling installation

5. MH-WS-1 | Contact us for pricing

BUNDLE of MH 1 & WS 1

WALL AND CEILING MOUNTS FOR LINE/ROTATING LASERS

6. WH-3 | Contact us for pricing

Robust mount for use on walls and ceilings
Ideal for setting out suspended ceilings
Platform size 146 x 50/105 mm
Cm/inch-graduation
Height adjustable range of 215 mm
1/4" & 5/8" connection

7. WH-2 | Contact us for pricing

All metal mount for use on walls and ceilings
Ideal for setting out suspended ceilings
Platform size 150 x 95 mm
Cm/inch-graduation
Precise adjustment with large slow motion wheel *Height adjustable range of 96 mm
1/4" & 5/8" connection

WALL MOUNTS FOR LINE LASERS

8. LH 2 | Contact us for pricing

L-Shape metal wall bracket for line & dot lasers

Use of laser in hanging /standing postition (depending on product)
Magnets on back side
Screw hole for wall-attachment
1/4" & 5/8" connection

9. LH 1 | Contact us for pricing

Multi-functional L-Shape wall mount for line & dot lasers

Use of laser in hanging / standing position (depending on product)
Height adjust. range 88 mm
Swivel-mount support rail to swing laser left/right 180°
Free-hanging tripod mount
Magnets on back side
Screw hole for wall-attachment *1/4" & 5/8" connection

THREAD ADAPTERS

10. A-58-14 | Contact us for pricing

Adapter 5/8“ to 1/4“

Converts a standard 5/8“ tripod into a 1/4“ fitting

11. A-14-58 | Contact us for pricing

Adapter 1/4“ to 5/8“

Converts a standard 1/4“ tripod into a 5/8“ fitting

DIAGNOSTIC PRODUCT

12. FWS 80 | Contact us for pricing

Wall-Detector FWS 80 .

For detection of metal, wood and living wires in ceiling, wall and floor.

Max. detection depth
-Ferrous metal 80 mm
-Non-ferrous metal 50 mm
-Live wiring 50 mm
-Wood stud 20 mm
LED indication
Center indication
AC detection and alert at any mode

MIXER

13. FM 1200 | Contact us for pricing

Mixer FM 1200 .

Successor to FM 1010 which will be discontinued .

More power but same price than FM 1010

Power 1200 W
150 - 650 rpm / 2 gear
Ergonomic handle *Paddle H2-120
Stirring capacity 15-35 kg
Weight 5,7 kg
Small box dimension 42x34x20 cm due to 2-part paddle

14. Paddle Extensions | Contact us for pricing

To extend paddle for more working ergonomics by avoiding a stooped working posture.

Available with:

Extension 100 mm x M14
Extension 200 mm x M14

IMPROVEMENTS - CHANGES

15. Metal clamp for receiver | Contact us for pricing

Metal Clamp for FR 77-MM / FR 77-MM TRACKING / FR 75-MM / FR-DIST 30 .

Very robust full-metal clamp
Bracket for squared and round poles.
Clamp fits to all of a.m. receivers ever bought

From now on all FR 77-MM, FR 77-MM TRACKING will be standardly equipped with metal clamp without surcharge!

GNSS-Systems

16. FGS Lite | Contact us for pricing

Improved Set & components:

8" Tablet Samsung Galaxy ActiveTab2
Robust RAM-Mount connection
GPS Rod G20 with interior cable routing
Improved version of geoFENNEL Survey Software (Android) with new functions

17. FGS 200 | Contact us for pricing

Slope measurement up to 60° in all directions
High performance even under critical conditions
Supports GPS, GLONASS, BeiDou, Galileo
Compact design *Long battery lifetime
Supports PPP and L-Band *Web based user interface

For more inquiries and info please CONTACT US.
